The Gold Hunter Pinpointer is a hand-held metal detector designed to precisely pinpoint metallic (ferrous and nonferrous) objects during target recovery. This pinpointer is intended for use in conjunction with a ground search metal detector to aid in the recovery of metallic evidence ( weapons,shell casings,projectiles,etc.) at crime scenes.
Gold Hunter Basic pinpointer has both audible and vibrating alarms to indicate the presence of metal objects.The alarms to indicate the presence of metal objects. The alarms increase in intensity as the pinpointer is moved closer to the metal target. With a pinpointing tip plus a scraping blade with side-scan capability, the basic pinpointer is very effective in easily detecting even the smallest of metallic objects. An LED flashlight assists in dark and low light conditions.
QUICK VIEW
- Accurately find small objects
- Prevent digging large holes
- Identify multiple objects in near proximity
- Search in tight interior areas(walls,ceilings)
- Serve as a utility pinpointer for locating metal pipes,conduit,rebar,etc.
FEATURES
| Power On / Off | Press and release the On/Off button, one (1) short warning tone will be heard and the LED will remain on. Then the pinpointer is ready for working. Be sure there are no metal objects around at start up. |
| Press and hold the On/Off button for a half second until you hear a single beep ( or single vibration in Silent Mode ),indicating turn off. | |
| Sensitivity Setting | Auto-tuning,without adjustment. |
| Detection Tip |
The Basic pinpointer’s detection area is between the tip and the hand grip. The coil provides 360° detection and this helps you to locate targets quickly and easily in the hole. The rate of the pulsing audio or vibrations will increase as it gets closer to the target and it will decrease as it is moved away. |
| Coil Interference Blocking | When it is switched off, it disconnects the coil’s magnetic transmission and eliminates interference with another metal detector. |
| Auto-Off Feature | After twenty minutes warning chirps, the pinpointers will turn off automatically. |
| Scraping Blade | This rugged edge is ideal for sifting through dirt while searching for the target. |
| Lanyard Attachment Clip | Use to attach the pinpointers to your belt, digging pouch or your detector (if desired). |
| Holster | Secure to any standard size belt. You will not lost your pinpointers again ! |
| Battery Replacement: | Simply rotate the battery cover counterclockwise to remove and clockwise to tighten by hand. |
PACKAGE INFORMATION
| Unit Dimensions | 9.13”x1.5”x1.62” (232 x 38 x 41mm),without packing |
| Detection Tip | 4.17” (106mm) |
| Weight | 7 oz. (0.2 kg), if with battery in |
| Model Name | GOLD HUNTER basic pinpointer |
| Control | Two buttons control, Power Switch button & Model Switch button |
| Alarm Model | Audio and / or Vibration alert / or both |
| Working Frequency | 11.6KHz |
| Working Temperature | -4°F / +122°F (-20°C / +50°C) |
| Battery | Single 9V Battery (not included) |
| Battery life | Carbon: 16 hours Alkaline: 30 hours Rechargeable: 8 hours |
| Warranty | Limited, 12 months |
-
